DRIVER SEATS
P1101/EA80H3
| Air suspension |
▲
|
| Air suspension with 12V or 24V built-in compressor |
●
|
| Mechanical suspension |
▲
|
| Weight adjustment |
Manual up to 150kgs. |
| Suspension stroke |
80mm |
| Height adjustment |
60mm |
| Optional suspension stroke |
60 mm - 100 mm
|
| Turn Table |
▲ |
| Adjustable shock absorber |
N/A |
| Slide travel |
190mm |
| Lumbar adjustment |
●
|
| Adjustable armrests |
▲ |
| Adjustable headrest |
●
|
| Backrest adjustment |
●
|
| Seat cushion tilt adjustment |
● |
| Seat cushion depth adjustment |
● |
| Vinyl trim |
● |
| Cloth trim |
▲ |
| Genuine leather trim |
▲ |
| 3-point seat belt |
▲ |
| 2-point seat belt |
▲ |
| Document box-pouch |
▲ |
| Front Controls |
N/A
|
| LH Controls |
● |
| RH Controls |
▲ |
| Heater |
▲ |
| Operator presence switch |
▲ |
| Slides between seat top and suspension |
N/A |
| Standard connection widths |
280mm |
| Optional connection widths |
216 - 230 - 260 - 320 - 328mm |
| Testing |
ECE R14 - M3 / N3
ECE R25.04
ECE R16.08
ECE R118.03
ECE R10 |
▲ : Option
● : Standard
N/A : Not Available
