DRIVER SEATS
P1201/A100H3
Air suspension |
●
|
Air suspension with 12V or 24V built-in compressor |
▲
|
Mechanical suspension |
▲
|
Weight adjustment |
Automatic up to 150kgs. |
Suspension stroke |
100mm |
Height adjustment |
60mm |
Optional suspension stroke |
60 mm - 80 mm |
Turn Table |
▲
|
Adjustable shock absorber |
N/A |
Slide travel |
190mm |
Lumbar adjustment |
▲
|
Adjustable armrests |
▲ |
Adjustable headrest |
N/A |
Backrest adjustment |
●
|
Seat cushion tilt adjustment |
●
|
Seat cushion depth adjustment |
●
|
Vinyl trim |
●
|
Cloth trim |
▲
|
Genuine leather trim |
▲
|
3-point seat belt |
▲ |
2-point seat belt |
▲
|
Front Controls |
N/A |
LH Controls |
●
|
RH Controls |
▲ |
Heater |
▲ |
Operator presence switch |
▲ |
Slides between seat top and suspension |
N/A |
Standard connection widths |
280mm |
Optional connection widths |
216 - 230 - 260 - 320 - 328mm |
Testing |
ECE R14- M3 / N3
ECE R25.04
ECE R16.08
ECE R118.03
ECE R10 |
▲ : Option
● : Standard
N/A : Not Available
