| Air suspension |
▲
|
| Air suspension with 12V or 24V built-in compressor |
▲
|
| Mechanical suspension |
●
|
| Weight adjustment |
Manual up to 150kgs. |
| Suspension stroke |
80mm |
| Optional suspension stroke |
60 mm - 100mm |
| Height adjustment |
60mm |
| Turn Table |
▲
|
| Adjustable shock absorber |
N/A |
| Slide travel |
190mm |
| Lumbar adjustment |
▲
|
| Adjustable armrests |
▲
|
| Adjustable headrest |
●
|
| Backrest adjustment |
●
|
| Seat cushion tilt adjustment |
●
|
| Seat cushion depth adjustment |
N/A |
| Vinyl trim |
●
|
| Cloth trim |
▲
|
| Genuine leather trim |
▲
|
| 3-point seat belt |
▲
|
| 2-point seat belt |
▲
|
| Document box-pouch |
▲
|
| Front Controls |
▲
|
| LH Controls |
●
|
| RH Controls |
▲
|
| Heater |
▲
|
| Operator presence switch |
▲
|
| Slides between seat top and suspension |
▲
|
| Standard connection widths |
216mm |
| Optional connection widths |
230 - 260 - 280 - 320 - 328mm |
| Testing |
ECE R14 - M3 / N3
ECE R16.08
ECE R118.03
ECE R10 |
