MATERIAL HANDLING SEATS
22/MN60
| Air suspension with 12V or 24V built-in compressor |
▲
|
| Mechanical suspension |
●
|
| Weight adjustment |
Manual up to 150kgs. |
| Suspension stroke |
60mm |
| Optional suspension stroke |
80mm |
| Height adjustment |
N/A
|
| Turn Table |
▲ |
| Slide travel |
210mm |
| Lumbar adjustment |
▲
|
| Hip restraints |
▲
|
| Adjustable / Foldable armrests |
▲
|
| Adjustable headrest |
▲
|
| Backrest adjustment |
●
|
| Vinyl trim (Vacuum type) |
●
|
| Cloth trim (Vacuum type) |
▲
|
| 2-point seat belt |
▲ |
| Document box-pouch |
▲
|
| Heater |
▲
|
| Operator presence switch |
▲
|
| Standard connection width |
328mm |
| Optional connection width |
320mm |
| Testing |
EN13490 IT1,IT2
ECE R16.08
ISO 3795 |
▲ : Option
● : Standard
N/A : Not Available
