CONSTRUCTION SEATS

F22/MN60

  • Technical Specification

  • DIMENSIONS

Air suspension N/A
Air suspension with 12V or 24V built-in compressor ▲
Mechanical suspension ●
Weight adjustment Manual up to 150kgs.
Suspension stroke 60mm
Optional suspension stroke 80mm
Height adjustment N/A
Turn Table ▲
Slide travel 210mm
Lumbar adjustment ▲
Adjustable / Foldable armrests ▲
Adjustable headrest ▲
Backrest adjustment ●
Vinyl trim (Vacuum type) ●
Cloth trim (Vacuum type) ▲
3-point seat belt N/A
N/A
2-point seat belt ▲
Document box-pouch ▲
Heater ▲
Operator presence switch ▲
Standard connection widths 328 mm
Optional connection width (factory option) 320 mm
Testing ISO 6683
ISO 7096-EM3,EM6,EM7,EM8
EN13490 - IT1,IT2
ECE R16.08
ISO 3795

▲ : Option ● : Standard N/A : Not Available
